GEOCHEMICAL CHARACTERISTICS OF THE ASPHALTENES IN THE SOLULE EXTRACT
-
摘要: 以花海盆地花深一井下新民堡群11块岩心样品,用苯-甲醇抽提物的沥青质,经元素、红外光谱、电子顺磁共振波谱分析,并参照核磁共振资料,研究了沥青质的性质、结构、有机质类型、烃类的形成和演化的关系。 探讨该盆地原始有机质属以腐殖型为主的混合型,初步证实沥青质的结构是稠核芳烃为主、在其侧链上连有短的烷基。该井样品随深度的演化明显分阶段性,1800米为其生油门限的深度。Abstract: This paper deals with the study on asphaltenes extractd by benzen-methyl alcohol from 11 source rocks from Huashen No 1 well of the Lower Xingmin Group (Cretaceous) in the Jinxi-Huahai basin, Northwest China. The relation between the porperties of the asphatenes and petroleum evolution is studied by elements analysis, infrared spectrum, electron spin resonance and nuclear magnetis resonamce. experiments 1. Method for preparing asphaltenes Source rocks are extracted by benzene-methyl alcohol (9:1) Asphaltenes are prepared in the standard way by two times of precipitation from the benzen-methyl alcohol extract with 10 parts of hexane. 2. Element analysis; Element analysis is performed on a ZWF-1-type element analyser and the percentages of are obtained. Then H/C atom rate and O/C atom rate are calclated. 3. Infrared spectrum: The analysis is made with the following method: Powder asphaltenes are prepared 0.25% bromine potassium piece Subsequent was scanned by the infrared spectrometer of IR-440 type. The result of infrared spectrum shows that the asphaltenes have the following fuctional group: the peaks at 2900 cm-1, 1380 cm-1, 2850 cm-1, 1450 cm-1 representing methyl and methylene respectively; and the peaks at 750cm-1, 810 cm-1, 860 cm-1, 1280 cm-1. 1620 cm-1. 3050 cm-1, reflecting aromatic hydrocarbon characteristic absorption peaks and the peaks at 1030 cm-1, 1650 cm-1, 1700 cm-1, 3400 cm-1, representing ether groups, quinone groups, carbonyl groups and NH group respectvel.y 4. Electron spin resonance: Powder asphaltenes are put in a glass tube with DPPH reference, then detected by the ESR-3 spectrometer at room temperature. Conclusion Based on the above data, the following ideas are conceived: 1) During oil formation the asphaltenes are the material of "interim type". Asphal-tene molecule consists of condensed nucleus benzen rings with alkylated side chain; 2) Properties of asphaltenes in structure are relatived to the types of the source materials. Organic parent materials in Huashen No 1 well belong to a mixture type which mainly contains humic substance. 3) The asphaltenes are heavy components of the soluble extract. The stages are observed from soure rocks in Hnashen No 1 well. The depth of 1357m-1768m is the lower mature stage while 1800m-2700m is the higher mature stage. The maximal threshold of the formation of crude oil is 1800m in Huashen No 1 well of the Huahai Basin.
-
[1] 程克明,1983,沥青质的地球化学性质及其对母源有机质的分类意义石油勘探与开发,第5期。 [2] T.F.Yen&J.G.Erdman,1962, Analyt.Chem.N.6,p.634. [3] G .V .Chelingarian&T.F.Yen, 1978, Bitumens Asphalts and Tar Sands,Developments in Petroleum Science 7 p.155-190.
